Sagemcom F@st 5260
Solid Orange LED. Gigabit Ethernet
link present.
Solid Orange LED with Flashing
Green LED. Gigabit Ethernet link
present with and passing Ethernet
traffic.

Side View

USB Port:
Reset Button:
WPS Button:
NOTE:
WPS push-button pairing mode must be enabled
through the Web UI before use.
The WPS button applies to both 2.4 GHz and 5 GHz
according to which is enabled.
Connects to your
storage and printing
devices.
Press and release to
reboot.
Press and hold for
15 seconds or more
for factory reset.
Press and hold for 5
seconds until WPS
light flashes to enable
WPS push-button
pairing mode.
Chapter 1: Product Overview

Label

The label is located on the back of your router. It contains
important information such as your SSID and router login
username and password as well your MAC address which you
will need to set up your router.
WAN MAC Address
Serial Number
Preset WiFi SSIDs and Password
Router Web GUI
Access
information
6
