Sagemcom F@st 5260

Appendices

Appendix A: Technical Specifications

Sagemcom F@st 5260 Specifications

Model Name Sagemcom F@st 5260
Ethernet Port Speed IEEE 802.3 Ethernet: 10-BASE-T, 100-
BASE-T, 1000-BASE-T
Wireless Standards 5GHz: IEEE 802.11ac 2.0, 802.11n,
802.11a
2.4GHz: IEEE 802.11n, 802.11g,
802.11b
2400MHz – 2483.5MHz
Wireless
Frequencies
5150MHz to 5350MHz
5470MHz-5850MHz (excluding
5600MHz – 5650MHz)
Wireless Security WEP, WPA, WPA2, WPA2-Enterprise
Support with RADIUS
Ports
Power, USB, Ethernet WAN, Ethernet
LAN (1-4)
Buttons Reset, WiFi Protected Setup, Power
Switch
LEDs
Front: WAN/Internet, LAN/Ethernet,
WiFi, WiFi Protected Setup, Power
Back: Internet WAN, Ethernet LAN (1-4)
UPnP Supported
DLNA Supported
Storage File System FAT16, FAT32, NTFS, Ext2, Ext3, Hfs,
Support Hfs+
Printer Protocol
IPP
Browser Support
Internet Explorer 8 or higher, Firefox 26
or higher, Chrome 32 or higher, and
Safari 4 or higher

Sagemcom F@st 5260 Physical Characteristics

8.7" x 2.6" x 8.1" (220 x 65.4 x 206 mm)
Dimensions
Weight 1.17 lbs (529 g)
Power
Input: 100V to 120V ~60Hz
Output: 12V DC @ 2.5A
Environmental Temperature 32°F to 104°F (0 °C to 40 °C)
Characteristics
Relative humidity 20 % to 90 %, non-
condensing
Altitude 6562 ft (2000m)
Appendices
34
