Summary of Contents for SAGEMCOM Fast 1704N
- Page 1 F@ST 1704N Quick Installation Guide...
- Page 2 F@ST 1704N Sagemcom thanks you for choosing the range of F@ST 1704N routers while hoping that it will provide you with full satisfaction. F@ST 1704N products adapt the ADSL function respectively on POTS (ITU G.992.1/3/5 - Appendix A) and on ISDN (ITU G.992.1/3/5 - Appendix B).
-
Page 3: Contents Of The Pack
F@ST 1704N Contents of the pack Before you carry out the installation, make sure that the pack contains the following elements: Item Description F@ST 1704N router Mains adapter ADSL line cable used to connect your router to your telephone line Ethernet cable used to connect your router to the Ethernet port of your computer Quick Installation Guide... -
Page 4: Safety Instructions
F@ST 1704N Safety instructions Power supply source • Do not cover the router’s power adapter. • The router comes with its own power adapter. Do not use another adapter. • This class II adapter does not need to be grounded (earthed). The connection to the electrical network should comply with the indications given on the label. - Page 5 F@ST 1704N • Do not expose the router to splashes of water. • Avoid blocking any vent openings or exhaust exits on this equipment. Do not place equipment in a built-in installation such as a cabinet that may impede the flow of air through the ventilation openings.
-
Page 6: For North America
F@ST 1704N For North America IMPORTANT SAFETY INSTRUCTIONS When using this equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • The equipment is for indoor use in dry locations. •... -
Page 7: Fcc Caution
F@ST 1704N FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 8: Fcc Radiation Exposure Statement
FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operation is subject to the following two conditions: •... - Page 9 Telephone Company will provide advance notice so you can make the necessary modifications to maintain uninterrupted service. This equipment is not user serviceable. If trouble is experienced with this equipment, for repair or warranty information, please contact your Service Provider, or Sagemcom at:...
- Page 10 F@ST 1704N +1 (972) 674-4100, or Sagemcom USA, 14651 N. Dallas Parkway, Suite 900, Dallas, TX 75254. If the equipment is causing harm to the telephone network, the Telephone Company may request that you disconnect the equipment until the problem is resolved.
- Page 11 F@ST 1704N The Ringer Equivalence Number is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.
- Page 12 F@ST 1704N This Class B digital apparatus complies with Canadian ICES-003. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. Cet appareil est conforme aux normes d'exemption de licence RSS d'Industry Canada.
- Page 13 F@ST 1704N Connection Connecting your router Make the connections as shown in the diagram below. Line Mains Phone set wall socket wall socket Filter/Spitter LINE PHONE Mains Adapter with its lead MODEM ADSL ETH4 ETH3 ETH2 ETH1 Line cord RESET LINE Connecting additional telephones Make the connections as shown in this diagram.
-
Page 14: Router Supervision
F@ST 1704N Router supervision You can monitor the router’s activity and status using the following sources: • status of the LEDs on the front and left panels of the router, • using the router’s built-in "DSL Router" HTTP controller, available in the HTTP configuration tool, accessible at http://myrouter or http://192.168.1.1. - Page 15 F@ST 1704N Status Meaning No link detected on the Ethernet port Green steady Ethernet port has detected a link with 100 Mbps device to 4) Green blinking Tx/Rx traffic at 100 Mbps No USB connection Green steady USB connection available Green blinking USB connection reading in progress WPS deactivated...
- Page 16 Draft URD 21-09-2012 All rights reserved. The information and specifications included are subject to change without prior notice. Sagemcom Broadband SAS tries to ensure that all information in this document is correct, but does not accept liability for error or omission.
