VIDEO DOOR ENTRY SYSTEM GB2 NEXA MODULAR - BUILDING
PUSH BUTTONS MODULE DESCRIPTION (EL610D)
Push buttons module description (EL610D):
Front side.
Push buttons module (x10).
Back side.
Input / output push buttons connector (x3).
Configuration dip switch
(Push buttons call code).
Push button number.
6
