KIT CONTENTS: We have organized the parts as they come out of the box for the better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
AIR FRAME ASSEMBLIES
. (2) Wing halves with ailerons
. (1) Fuselage
. (1) Horizontal stabilizer with elevator halves
. (1) Vertical stabilizer with rudder
. (1) Cowling
. (1) Decal sheet
. (1) Instruction manual
MAIN GEAR ASSEMBLY
. (2) Main gears
. (2) 60mm diameter wheels
. (4) Wheel collars
. (2) Wheel pants and accessories
. (4) 4mm x 15mm screws
. (4) Washers
TAIL GEAR ASSEMBLY
. (1) Set of tail gear
ELEVATOR CONTROL SYSTEM
. (1) Control horn
. (1) Clevis
. (1) Silicon tube
. (1) Snap keeper
. (2) 2mm x 12mm screws
. (1) Metal wire 85cm

KIT CONTENTS

1
RUDDER CONTROL SYSTEM
. (1) Control horn
. (1) Clevis
. (1) Silicon tube
. (1) Snap keeper
. (2) 2mm x 12mm screws
. (1) Metal wire 85cm
AILERON CONTROL SYSTEM
. (2) Metal rods (2mm x 180mm)
. (4) 2mm x 20 mm screws
. (2) Control horns
. (2) Silicon tubes
. (2) Nylon snap keepers
. (2) Clevises
MOTOR MOUNT ASSEMBLY
. (1) Wooden Engine mount
. (4) 3mm x 10mm screws
. (4) Washer
MISCELLANEOUS ITEMS
. (1) Dihedral
. (2) 25 mm x 200 mm trim tapes
. (2) Nylon screws
. (2) Nylon bushings
. (4) 2.6 mm x 10 mm screws
