Leveling the Build Plate

Finder creatively adopts three-point intelligent leveling system, which will give clear and comprehensive feedback to users.
There are three spring-loaded nuts under the build platform. The distance between the plate and the nozzle increases while
tightening the nuts. On the contrary, the distance reduces.
Screw home the three nuts under the plate
anticlockwise and then tap [OK].
OK
1. Turn the power on. The touch screen
panel lights up and displays menus. Tap
[Tools]-[Level] to level the build plate.
Screw home the three nuts under the
plate anticlockwise and then tap [OK].
Over-distance
Unscrew the corresponding
正在进行调平过程...
nut under the extruder until
you hear a continuous beep.
等待
3. If over-distance, please unscrew the
corresponding nut under the extruder
until you hear a continuous beep.
Tap [OK] to continue.
Under-distance
Screw the corresponding
正在进行调平过程...
nut under the extruder until
you hear a continuous beep.
等待
2. The extruder start to move towards the first point and the plate moves up and down
to detect the distance between the nozzle and the plate. If under-distance, please
screw the corresponding nut under the extruder until you hear a continuous beep and
the direction arrow turns into [OK]. Tap [OK] to continue.
Leveling...
Wait
4. The plate will make a detect again, if the
distance isn't appropriate, you should
adjust it again. If appropriate, the extruder
will move to another point.
Under-distance
Screw the corresponding
正在进行调平过程...
nut under the extruder until
you hear a continuous beep.
OK
等待
Completed!
Finish
5. When the extruder halts over the second
nut, repeat the above steps and then go
on to the third nut to complete leveling.
