EVALUATION BOARD HARDWARE

DEVICE DESCRIPTION

The AD7625/AD7626 are 6 MSPS/10 MSPS, high precision,
power efficient, 16-bit PulSAR ADCs that use SAR based
architecture and do not exhibit any pipeline delay or latency.
The AD7625/AD7626 are specified for use with 5 V and 2.5 V
supplies (VDD1, VDD2). The interfaces from the digital host to
the AD7625/AD7626 use 2.5 V logic only.
The AD7625/AD7626 use an LVDS interface to transfer data
conversions. Complete specifications for the
are provided in the respective product data sheets, which should
be consulted in conjunction with this user guide when using the
EVAL-AD7625FMCZ/EVAL-AD7626FMCZ
Full details on the EVAL-SDP-CH1Z
product page on the Analog Devices website.

HARDWARE LINK OPTIONS

The default link settings on the board and the function of the
link options are described in Table 1.
Table 1. Pin Jumper Descriptions
Link Default
JP1, JP2 B to center
JP6 B to center
JP10 B to center
JP11, JP12 B to center
JP13, JP14 B to center
LK2 Inserted
LK3 Inserted
LK6 B
LK9 A
LK10 A
Table 2. On-Board Connectors
Connector Description
J1 SMA low noise, low jitter clock source input.
J2, J10 SMA CNV input. This option is for using the external CNV signal.
J3, J5, J6, J8 SMA analog input. Connects the low noise analog signal source to the inputs of the ADC driver ADA4899-1, ADA4897-1, or
ADA4932-1.
J4 3-pin terminal. This option is for using external bench top supplies. Apply external +V
the EVAL-AD7625FMCZ/EVAL-AD7626FMCZ
J9 6-pin (2 × 3) socket. This option is for interfacing with an external ADC driver board.
J7 160-pin FMC 10 mm male VITA 57 connector. This connector mates with the
J11, J12 SMA low noise, low jitter clock output from the AD9513.
EVAL-AD7625FMCZ/EVAL-AD7626FMCZ User Guide
AD7625/AD7626
evaluation boards.
are available at the SDP
Description
Connects CNV+ and CNV− from the FPGA. The A to center position connects the CNV signal from the AD9513.
Connects 7 V to amplifier +V
S
Connects −2.5 V to amplifier −V
Connects analog inputs VIN+ and VIN− to the inputs of the ADC driver
center position sets the fully differential path through the ADA4932-1.
Connect outputs from the ADA4899-1
differential path through the ADA4932-1.
Connects REFIN to the1.2 V external reference.
Connects the 4.096 V output from the
Connects the output of the VCM buffer to the VCM of the amplifier.
Connects to the 7 V supply coming from the ADP7102.
Connects to the −2.5 V coming from the ADP2300.
boards.

POWER SUPPLIES

The power (12 V) for the
AD7626FMCZ
FMC connector (J7) from the
The user also has the option of using external bench top supplies
to power the on-board amplifiers. The on-board regulators
generate the required levels from the applied 12 V rail.
The ADP7102
amplifiers (ADA4899-1
ADR4540 (U14). The
(U1), the external reference
and the ADP124
−2.5 V for the amplifier –V
a 2.5 V supply for VDD2 and VIO (U1).
The 3.3 V supply for the EEPROM (U7) comes from the
SDP-CH1Z through a 160-pin FMC connector (J7). Each supply
is decoupled where it enters the board and again at each device.
A single ground plane is used on this board to minimize the
effect of high frequency noise interference.
.
.
S
to the inputs of the ADC. The A to center position sets the fully
ADR4540 after buffer AD8031.
