UG-745

BILL OF MATERIALS

Table 4. Bill of Materials for EVAL-AD7626FMCZ
Name
+5V, +7V, −2P5V, 1PT2V_REFIN,
2PT5V, 3PT3V, 4PT096V_REF,
AMP_PWR+1, AMP_PWR−1
VADJ
VCM, VCM_BUF, VIO_2PT5V
REF
REFIN1
C1, C2, C3, C4, C5, C6, C7, C19
C8, C9, C10, C38, C69, C70
C11, C12, C13, C14, C16, C17, C18
C15
C20
C21
C22
C23, C24
C26, C39, C49, C51, C54, C55, C79,
C81, C83 C84, C85, C86, C87, C47,
C61, C66
C27, C28, C29, C30, C31, C32, C33
C43
C44, C45, C46
C48, C42, C53, C58, C60, C62, C65, C71
C56
C57, C76
C63, C64, C68, C72
C77, C78, C80, C82
C88, C89
D3
GND1, GND2, GND3, GND4, GND5
J1
J2, J10
J3, J5
J4
J6, J8
J7
J9
J11, J12
JP1, JP2, JP6, JP10, JP11, JP12,
JP13, JP14
L1
L2
L3
LK2, LK3
LK6
LK9
LK10
R1, R2
R3
R4
R5, R6, R8
EVAL-AD7625FMCZ/EVAL-AD7626FMCZ User Guide
1
Part Description
Test point
Test point
Test point
Test point
Test point
Capacitor 0603
Capacitor+
Capacitor 0603
Capacitor 0603
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor
Capacitor 0603
Capacitor 0603
Capacitor
Capacitor 0603
Capacitor 0603
Diode Schottky, 30 V, 1 A, PD3S130L
Test point
Switching mode amplifier (SMA)
SMA
SMA
Connector\Power3
SMA
ASP-134604-01
Header 06-SKT-RA
SMA
3W, solder link, 0603
Bead, 0805
Inductor
Bead
Jumper
Jumper2\solder bridge
Jumper-2
Jumper-2
Resistor
Resistor
Resistor
Resistor
Rev. A | Page 26 of 28
Part Number
20-313137
N/A
20-313137
20-313137
20-313137
MCCA000050
EMK212B7475KG-T
C1608X5R1A106M
MCCA000076
06035A100JAT2A
MCCA000255
GRM21BR60J226ME39L
GRM1555C1H102JA01D
MCCA000255
MCCA000050
EMK212B7225KG-T
TBA
GRM219R61C106KA73D
N/A
06035A560JAT2A
LMK107B7105KA-T
N/A
C1608C0G1H101J080AA
PD3S130L
20-313137
5-1814832-1
142-0701-851
5-1814400-1
CTB5000/3
142-0701-851
ASP-134604-01
SSW-103-02-T-D-RA
5-1814832-1
N/A
HZ0805E601R
LPS3015-472MLB
7427-92642
M20-9990246
N/A
M20-9980445
M20-9980446
RC0402FR-07100RL
ERJ-2RKF1000X
MC01W0805110R
MC 0.0625W 0402 1% 10K
Stock Code
FEC 8731144
Do not insert
FEC 8731144
FEC 8731144
Not inserted
FEC 1758896
FEC 2112841
FEC 1962113
FEC 1758924
FEC 499110
FEC 1759122
Digi-Key 490-1719-1-ND
FEC 8819556
FEC 1759122
FEC 1758896
FEC 1683654
Do not place
FEC 1845747
Do not place
FEC 2280650
FEC 2112849
Do not place
FEC 1907297
Digi-Key PD3S130LDICT-ND
FEC 8731144
FEC 1248990
Not inserted
Not inserted
FEC 151790
Digi-Key J658-ND
Samtec ASP-134604-01
Not inserted
Not inserted
N/A
Digi-Key 240-1018-1-ND
Coilcraft LPS3015-472MLB
FEC 1635690
FEC 1022247 and FEC 150-411
N/A
FEC 1022232 and FEC 150-411
FEC 1022232 and FEC 150-412
FEC 9239111
FEC 2304034
FEC 9332421
FEC 1358069
