2.THE OPERATING CONTROL SYSTEMS
-REPLACING THE CONTROL CIRCUIT BOARD
WARNING :
This Device is to be Serviced Only by Properly Qualified Service Personnel.
Consult the Service Manual for Proper Service Procedures to Assure Continued Safety Operation and for
Precautions to be Taken to Avoid Possible Exposure to Excessive Microwave Energy.
1. Remove two screws on the top of the microwave oven for the vent grille and remove the grille(See FIG. 1).
Refer to FIG. 2, FIG. 2-1 for the following steps:
2. Remove the screw on the front of the microwave oven for wire protector and remove the wire protector.
3. From the top and back of the control panel, lift the top locking tab and pull the top of the panel out slightly, then lift the
bottom tabs of the panel out of the slots and pull it forward.
FIG. 2
