13. REPLACING THE VENTILATION MOTOR
CAUTION :
Personal Injury Hazard
Because of the weight and size of the microwave oven, two people are required to safely move and install it
Failure to do so could result in personal injury.
1. Remove the microwave oven from the microwave oven location.
2. Remove the screw for the vent motor cover and remove it. (See cabinet removal, FIG.1).
3. Remove the screw for the case blow fan top and remove it.
4. Remove 2 screws for the vent motor and lift it.
5. Unplug the wire connectors for vent motor.
6. Connect the wire connector and secure the vent motor.
7. Install the new vent motor.
8. Reinstall the case blow fan top and the vent motor cover and remount the oven.
FIG. 13
