4. REPLACING THE LINE FUSE
WARNING :
Personal Injury Hazard
Disconnect from the power supply before servicing the unit. Failure to do so could result in electric shock or
other per sonal injury.
1. Remove 2 screws from the vent grille and remove the grille (See FIG. 1).
2. Remove the screw from the front of the microwave oven for wire protector and control panel and remove control panel
and the wire protector(see Fig. 2).
3. Without touching the metal ends, remove the defective line fuse from the line filter and install a new one in it s place.
4. Mount the wire protector and the control panel to the oven and secure it with it s mounting screw.
5. Mount the vent grille to the microwave oven and check out the operation.
FIG. 4
