3. REPLACING AN OVEN LIGHT SOCKET
WARNING :
Personal Injury Hazard
Disconnect from the power supply before servicing the unit. Failure to do so could result in electric shock or
other personal injury.
1. Remove the screws for the vent grille and remove the grille.(See FIG.1)
2. Remove the cavity lamp cover(See FIG.3).
3. Remove the old light and mount a new light in its place .
4. Reinstall the cavity lamp cover into its air guide top.
5. Mount the vent grille to the microwave oven and check out the operation.
FIG. 3
10
