1. GENERAL
-REMOVING / REINSTALLING
WARNING :
Personal Injury Hazard
Disconnect from the power supply before servicing the unit. Failure to do so could result in electric shock or
other personal injury.
CAUTION :
Personal Injury Hazard
Because of the weight and size of the microwave oven, two people are required to safely move and install it.
Failure to do so could result in personal injury.
-CABINET
CABINET REMOVAL
Refer to FIG. 1 for the following steps:
1. Remove the microwave oven from its mounting location and set it on a protected (padded) work surface.
2. Remove the two screws from the top of the microwave oven that secure the vent grille to the oven, and pull the top of
the vent grille out so the tabs are from their slots, and remove it.
3. Remove 1 screw from the vent motor cover.
4. Remove the remaining 13 screws from the top, side and rear of the cabinet. Slide the cabinet back and unhook it from
the side tabs, then slide the power cord into the cabinet, and lift the cabinet from the oven.
Proceed to the section for the component you wish to service.
CABINET INSTALLATION
Refer to FIG. 1 for the following steps:
1. Position the cabinet over the top of the microwave oven and slide the power cord all the way through the top opening.
2. Slide the cabinet forward so that the tabs along the sides of the microwave oven fit into the corresponding slots in the -
cabinet and tighten the screws.
3. Install the vent grille on the oven with two screws.
4. Install the oven in its mounting location.
