SECTION 6.

[CONTROL UNIT]

REF PARTS
NO. NO.
IC2 1140016220 S.IC STM32F101VFT6 <TOMEN>
IC6 1180003480 S.REG NJU7772F33-TE1-#ZZZB
IC7 1110006490 S.IC LMV321IDCKR
IC8 1130017190 S.IC UC6528XBNQ4GRC <GOS>
Q3 1530002851 S.TRA 2SC4116-BL(TE85RF)
Q6 1590004040 S.TRA LDTA123YET1G <SLVJ>
D1 1750001820 S.DIO LRB706F-40T1G <SLVJ>
D2 1750001820 S.DIO LRB706F-40T1G <SLVJ>
D3 1750001810 S.DIO L1SS400T1G <SLVJ>
D4 1750001810 S.DIO L1SS400T1G <SLVJ>
D5 1750001810 S.DIO L1SS400T1G <SLVJ>
X1 6050013180 S.XTA CR-910(HC-49US/9.8304 MHz)
<JJE>
R1 7210003660 VAR R09461GO-FF17S5.0-B504
<EVT>
R2 7210003660 VAR R09461GO-FF17S5.0-B504
<EVT>
R3 7510001770 S.THE NTCG10 4LH 473JT
R4 7030007350 S.RES ERJ2GEJ 393 X (39K)
R5 7030005240 S.RES ERJ2GEJ 473 X (47K)
R6 7030005240 S.RES ERJ2GEJ 473 X (47K)
R7 7030005240 S.RES ERJ2GEJ 473 X (47K)
R11 7030005530 S.RES ERJ2GEJ 100 X (10)
R14 7030005530 S.RES ERJ2GEJ 100 X (10)
R16 7410000720 S.ARR EXB-V8V 473JV (47K)
R18 7410001130 S.ARR EXB28V102JX
R19 7030005160 S.RES ERJ2GEJ 105 X (1M)
R20 7030010040 S.RES ERJ2GEJ-JPW
R21 7030005530 S.RES ERJ2GEJ 100 X (10)
R27 7030005050 S.RES ERJ2GEJ 103 X (10K)
R33 7030005240 S.RES ERJ2GEJ 473 X (47K)
R34 7030005050 S.RES ERJ2GEJ 103 X (10K)
R36 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R37 7030005050 S.RES ERJ2GEJ 103 X (10K)
R39 7030005530 S.RES ERJ2GEJ 100 X (10)
R44 7030005090 S.RES ERJ2GEJ 104 X (100K)
R47 7030010040 S.RES ERJ2GEJ-JPW
R50 7030010040 S.RES ERJ2GEJ-JPW
R51 7030010040 S.RES ERJ2GEJ-JPW
R52 7030005120 S.RES ERJ2GEJ 102 X (1K)
R53 7030005120 S.RES ERJ2GEJ 102 X (1K)
R56 7030005240 S.RES ERJ2GEJ 473 X (47K)
R58 7410000720 S.ARR EXB-V8V 473JV (47K)
R59 7030005240 S.RES ERJ2GEJ 473 X (47K)
R63 7030005240 S.RES ERJ2GEJ 473 X (47K)
R67 7030005240 S.RES ERJ2GEJ 473 X (47K)
R68 7030005090 S.RES ERJ2GEJ 104 X (100K)
R69 7030005240 S.RES ERJ2GEJ 473 X (47K)
R70 7030005090 S.RES ERJ2GEJ 104 X (100K)
R71 7030005240 S.RES ERJ2GEJ 473 X (47K)
R72 7030005240 S.RES ERJ2GEJ 473 X (47K)
R73 7030005240 S.RES ERJ2GEJ 473 X (47K)
R74 7030003860 S.RES ERJ3GE JPW V
C1 4030016790 S.CER C1005 JB 1E 103K-T
C2 4030016930 S.CER C1005 JB 1A 104K-T
C3 4030016930 S.CER C1005 JB 1A 104K-T
C4 4030017460 S.CER C1005 JB 1H 102K-T
C10 4030016790 S.CER C1005 JB 1E 103K-T
C15 4030016790 S.CER C1005 JB 1E 103K-T
C16 4030017780 S.CER C1005 JB 1H 472K-T
C17 4030017780 S.CER C1005 JB 1H 472K-T
C18 4030017650 S.CER C1005 CH 1H 270J-T
C19 4030017650 S.CER C1005 CH 1H 270J-T
C20 4030017780 S.CER C1005 JB 1H 472K-T
C21 4030017780 S.CER C1005 JB 1H 472K-T
C22 4030019560 S.CER GRM21BB31C106KE15L
C23 4030016790 S.CER C1005 JB 1E 103K-T
C24 4030017460 S.CER C1005 JB 1H 102K-T
C25 4030019560 S.CER GRM21BB31C106KE15L
C27 4030016930 S.CER C1005 JB 1A 104K-T
C28 4030016790 S.CER C1005 JB 1E 103K-T
C29 4030016930 S.CER C1005 JB 1A 104K-T
C32 4030019560 S.CER GRM21BB31C106KE15L
C34 4030016930 S.CER C1005 JB 1A 104K-T
C36 4030017460 S.CER C1005 JB 1H 102K-T
C37 4030016930 S.CER C1005 JB 1A 104K-T
C38 4030016930 S.CER C1005 JB 1A 104K-T
C39 4030017460 S.CER C1005 JB 1H 102K-T
C40 4030020000 S.CER C1005 JB 1A 105K-T
C41 4030017040 S.CER C1005 JB 1A 333K-T
C42 4030019560 S.CER GRM21BB31C106KE15L
C45 4030020000 S.CER C1005 JB 1A 105K-T
C46 4030017440 S.CER C1005 CH 1H 221J-T
C57 4030016790 S.CER C1005 JB 1E 103K-T
C58 4030017440 S.CER C1005 CH 1H 221J-T
C71 4030016930 S.CER C1005 JB 1A 104K-T
C72 4030016930 S.CER C1005 JB 1A 104K-T
C73 4030021580 S.CER GRM188B31E225KA12D
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.

PARTS LIST

DESCRIPTION M.
LOCATION
B 84.3/89.3
T 21.1/39.1
B 95.4/32.0
B 27.1/45.0
B 95.9/28.2
B 82.9/43.4
T 23.2/35.9
T 20.7/35.9
B 87.7/43.2
B 69.2/29.7
B 44.1/27.6
T 50.5/4.3
T 92.8/29.9
T 93.7/28.3
T 60.9/22.3
T 60.9/23.2
T 61.3/15.5
T 29.6/7.3
T 57.0/61.4
B 32.8/5.5
B 52.2/13.3
T 50.7/7.4
T 51.2/8.3
T 56.0/7.8
T 28.0/35.0
B 93.9/34.3
B 97.2/33.6
B 97.2/32.0
B 95.7/30.1
B 98.0/29.1
T 50.0/28.2
B 60.9/13.4
T 53.7/61.2
B 81.5/45.8
T 18.7/36.1
T 18.7/37.0
T 51.0/28.2
B 45.3/10.7
T 31.6/8.5
T 30.5/9.9
T 55.8/62.6
T 55.8/61.7
T 52.1/62.6
T 55.8/60.8
B 95.1/34.7
B 70.5/30.0
B 44.9/30.0
T 16.2/34.6
T 72.1/41.2
T 57.5/62.6
T 92.8/28.3
T 167.7/39.8
T 30.5/8.5
B 84.4/43.2
B 50.9/10.4
B 51.8/10.4
T 49.1/7.4
T 52.3/7.4
B 52.7/10.4
B 53.6/10.4
T 58.2/6.5
T 54.8/7.4
B 87.3/44.3
T 58.2/8.3
T 49.3/8.3
T 54.8/8.3
T 42.6/10.6
T 45.4/29.2
T 60.5/12.9
B 85.3/43.2
T 60.5/24.5
T 44.5/27.8
T 29.4/38.5
T 21.8/41.3
T 26.7/39.3
T 18.4/39.1
B 95.1/33.8
T 18.9/34.9
B 93.7/31.5
T 18.0/34.9
B 30.1/46.4
B 24.2/43.5
T 77.2/21.4
[CONTROL UNIT]
H/V REF PARTS
NO. NO.
C74 4030021580 S.CER GRM188B31E225KA12D
C75 4030021580 S.CER GRM188B31E225KA12D
C76 4030021580 S.CER GRM188B31E225KA12D
C77 4030021580 S.CER GRM188B31E225KA12D
C78 4030021580 S.CER GRM188B31E225KA12D
C79 4030021580 S.CER GRM188B31E225KA12D
C80 4030021580 S.CER GRM188B31E225KA12D
C81 4030021580 S.CER GRM188B31E225KA12D
C82 4030021580 S.CER GRM188B31E225KA12D
C83 4030021580 S.CER GRM188B31E225KA12D
C84 4030021580 S.CER GRM188B31E225KA12D
C85 4030021580 S.CER GRM188B31E225KA12D
C86 4030021580 S.CER GRM188B31E225KA12D
C87 4030021580 S.CER GRM188B31E225KA12D
C88 4030021580 S.CER GRM188B31E225KA12D
J1 6510027710 S.CON S5B-ZR-SM4A-TF(LF)(SN)
J2 6510028740 S.CON 14FLH-SM1-TB(LF)(SN)
J3 6510028880 S.CON 04-6238-010-410-800
J5 6510030110 S.CON IMSA-9681S-38Y901
J6 6450002260 CON
J7 6510030080 S.CON IMSA-9632S-04Y800
DS1 5030003870 LCD
S4 2250000880 ENC
S5 2250000880 ENC
S6 2260002740 S.SWI
S7 2260002740 S.SWI
W1 8910000210 FFC
EP1 6910024590 E.O
EP2 6910018460 S.BEA
EP3 6910018460 S.BEA
EP5 6910012350 S.BEA
EP6 6910012350 S.BEA
EP7 6910012350 S.BEA
EP8 6910018460 S.BEA
EP9 6910018460 S.BEA
EP10 6910018460 S.BEA
EP11 6910018460 S.BEA
EP12 6910018460 S.BEA
EP13 6910024430 E.O
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-1
DESCRIPTION M.
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
6606A-B11G ROHS <KTC>
B
JIC-MSGF013343-01 <RYOYO>
EC12E2420801
EC12E2420801
LS8J2M-T T
LS8J2M-T B
FFC-1026 (P0.5N10L80) <TJM>
WT5039-E <SKD>
MMZ1005Y102C-T T
MMZ1005Y102C-T T
MMZ1608Y 102BT T
MMZ1608Y 102BT T
MMZ1608Y 102BT T
MMZ1005Y102C-T B
MMZ1005Y102C-T B
MMZ1005Y102C-T B
MMZ1005Y102C-T B
MMZ1005Y102C-T T
GPS-123B-077
S.=Surface mount
H/V
LOCATION
77.8/25.8
76.2/29.3
80.4/21.4
82.5/21.4
83.1/25.8
88.0/20.5
84.6/29.3
88.0/22.6
88.0/24.7
82.5/29.3
80.4/29.3
78.3/29.3
86.7/30.1
88.8/30.1
88.0/26.8
54.0/67.9
32.8/2.8
86.1/46.9
86.7/24.2
20.0/46.2
168.6/35.5
28.2/35.5
44.1/30.8
15.7/32.6
16.2/35.8
16.2/37.0
16.2/38.2
25.5/33.0
93.7/29.9
92.8/29.9
88.2/27.2
22.3/42.8
