MP5(CONTROL)
(8930089020)
MP1(CONTROL)
(Refer to the list.)
MP8(CONTROL)
(8610014681)
MP7(CONTROL)
(8610014670)
MP8(CONTROL)
(8610014681)
MP7(CONTROL)
MP17(CONTROL) (8610014670)
(8310085160)
EP1(CONTROL)
(6910024590)

• GENERAL WIRING

W1(CONTROL)
GPS W2
J3 J6
(8910000210)
(EP13) (Optional)
LCD
Speaker
J5
(DS1) SP1(CHASSIS)
Touch
HM-207
panel J7
(Optional)
(EP1)
CONTROL UNIT
MP11(CONTROL)x4
(8810009221)
DS1(CONTROL)
MP16(CONTROL)
(5030003870)
(8930064320)
MP4(CONTROL)
(8930089010)
MP9(CONTROL)
(8610014690)
DC cable
W300(MAIN)
(8900015130)
J300
J103
Cooling fan
J6
MF1(CHASSIS)
J100
MAIN UNIT
MP8(CHASSIS)
(8810009611)
MP2(CONTROL)
(8210029710)
MP12(CONTROL)
(8810009221)
MP6(CONTROL)
(8930089520)
EP13(CONTROL)
(6910024430)
MP11(CONTROL)
(8810009221)
MP3(CONTROL)
(8930089000)
MP2(CHASSIS)
(8210029460)
MP15(CHASSIS)
Legend:
Ref. No.
Unit Name
MP1 (CHASSIS)
(1234567890)
MP9(CHASSIS)x13
Parts No.
MP8(CHASSIS)x2
(8810009611)
MP3(CHASSIS)
(8110010550)
W1(CHASSIS)
(8600036881)
SP1(CHASSIS)
(2510001160)
MP6(CHASSIS)
MP5(CHASSIS)
(8930078590)
(8110009020)
MP7(CHASSIS)
MF1(CHASSIS)
(8930089330)
(2710000820)
MP1(CHASSIS)
(8010022980)
IC3(MAIN)
(1150002423)
IC4(MAIN)
(1150002400)
MP213(MAIN)
MP213(MAIN)
(8930059770)
(8930059770)
(8310081740)
MP212(MAIN)
(8930060270)
MP212(MAIN)
(8930060270)
MP16(CHASSIS)
(8930089600)
MP17(CHASSIS)
(8810007410)
(8810008661)
MP4(CHASSIS)
(8110010540)
MP8(CHASSIS)x4
(8810009611)
NOTE: When replacing a flat cable, form the new one in the same shape as the original.
7-2
MP8(CHASSIS)x4
(8810009611)
MP8(CHASSIS)
(8810009611)
W300(MAIN)
(8900015130)
MP12(CHASSIS)x4
(8810010141)
MP11(CHASSIS)x2
(8810008661)
J1(CHASSIS)
(6510004881)
MP10(CHASSIS)x4
(8810008661)
MP8(CHASSIS)x2
(8810009611)
