Section 6 Parts List - Icom IC-F24/S Service Manual Addendum

SECTION 6.
[MAIN UNIT] (For other than F26-L)
REF PARTS
DESCRIPTION
NO. NO.
IC1 1110003201 S.IC TA31136FNG (EL)
IC2 1130008561 S.IC TC75S51F (TE85L,F)
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1
IC5 1110005340 S.IC NJM12902V-TE1-#ZZZB
IC6 1110005320 S.IC NJM13403V-TE1-#ZZZB
IC7 1110005330 S.IC NJM12904V-TE1-#ZZZB
IC8 1190000350 S.IC M62363FP-650C
IC9 1110005350 S.IC NJM2870F05-TE1-#FZZB
IC10 1130011770 S.IC CD4066BPWR
IC12 1110001811 S.IC TA7368FG (5,ER)
IC13 1140012721 S.IC HD6433687C73FPV
IC14 1110006260 S.IC BD5242G-TR
IC15 1130011540 S.IC BR24L16FV-WE2
Q1 1560000841 S.FET 2SK1829 (TE85R,F)
Q2 1580000731 S.FET 3SK293 (TE85L,F)
Q3 1580000760 S.FET 3SK299-T1 U73
Q4 1530002601 S.TR 2SC4215-O (TE85R,F)
Q5 1530000371 S.TR 2SC3356-T1B S (R25)
Q6 1590003230 S.TR UNR9113J-(TX)
Q7 1560001232 S.FET RD07MVS2-T112
Q8 1560001241 S.FET RD01MUS1-T113
Q9 1530003311 S.TR 2SC5107-O (TE85R,F)
Q10 1530003311 S.TR 2SC5107-O (TE85R,F)
Q11 1530003311 S.TR 2SC5107-O (TE85R,F)
Q12 1530003311 S.TR 2SC5107-O (TE85R,F)
Q13 1530002920 S.TR 2SC4226-T1 R25
Q14 1530002920 S.TR 2SC4226-T1 R25
Q15 1590001400 S.TR XP1214 (TX)
Q16 1590003290 S.TR UNR9213J-(TX)
Q17 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q18 1560000541 S.FET 2SK880-Y (T5RICOM,F)
Q19 1530002851 S.TR 2SC4116-BL (TE85R,F)
Q21 1510000920 S.TR 2SA1577T106 Q
Q22 1510000920 S.TR 2SA1577T106 Q
Q23 1520000460 S.TR 2SB1132T100 R
Q24 1590001190 S.TR XP6501-(TX) .AB
Q25 1590003230 S.TR UNR9113J-(TX)
Q26 1590003290 S.TR UNR9213J-(TX)
Q27 1590003290 S.TR UNR9213J-(TX)
Q28 1590003430 S.TR UNR911HJ-(TX)
Q29 1590003270 S.TR UNR9210J-(TX)
Q30 1510001080 S.TR 2SA2048TLR
Q31 1590001190 S.TR XP6501-(TX) .AB
Q32 1590003020 S.TR XP4216-(TX)
Q33 1590003230 S.TR UNR9113J-(TX)
Q34 1560001360 S.FET 2SK3019TL
Q35 1560001360 S.FET 2SK3019TL
D1 1750001080 S.DIO RB886GT2R
D2 1750000581 S.DIO 1SV307 (TPH3,F)
D3 1750000711 S.VCP HVC350BTRF-E
D4 1750000711 S.VCP HVC350BTRF-E
D5 1790001260 S.DIO MA2S077-(TX)
D6 1790001240 S.DIO MA2S728-(TX)
D7 1750000711 S.VCP HVC350BTRF-E
D8 1750000711 S.VCP HVC350BTRF-E
D9 1750000711 S.VCP HVC350BTRF-E
D10 1750000711 S.VCP HVC350BTRF-E
D14 1790001260 S.DIO MA2S077-(TX)
D15 1790001260 S.DIO MA2S077-(TX)
D16 1750000711 S.VCP HVC350BTRF-E
D17 1750000711 S.VCP HVC350BTRF-E
D18 1720000570 S.VCP MA368 (TX)
D21 1750000711 S.VCP HVC350BTRF-E
D22 1750000711 S.VCP HVC350BTRF-E
D24 1790001250 S.DIO MA2S111-(TX)
D25 1790001250 S.DIO MA2S111-(TX)
D26 1790001790 S.DIO RB876WTL
D27 1750000520 S.DIO DAN222TL
D28 1790001260 S.DIO MA2S077-(TX)
D29 1750000940 S.DIO ISS400TE61
D30 1750001080 S.DIO RB886GT2R
D31 1790001010 S.ZEN MA8043-L (TX)
FI1 2030000150 S.MLH FL-335 (46.350 MHz)
FI2 2020001840 CER ALFYM450F=K
FI3 2040001440 S.LC NFE31PT152Z1E9L
X1 6070000191 S.DCR CDBKB450KCAY24-R0
X2 6050011940 S.XTL CR-783 (15.3 MHz)
X3 6050011720 S.XTL CR-764 (19.6608 MHz)
L1 6200012490 S.COL 0.30-0.9-6TR 13.6N <COMO>
L2 6200013010 S.COL 0.30-0.9-5TL 10.3N <COMO>
L3 6200012610 S.COL 0.40-0.9-2TL 2.8N <COMO>
L4 6200012610 S.COL 0.40-0.9-2TL 2.8N <COMO>
L5 6200009070 S.COL LQW18AN18NG00D [High band]
6200010850 S.COL LQW18AN22NG00D
L7 6200007690 S.COL LQW2BHN18NJ03L
6200007700 S.COL LQW2BHN22NJ03L
L8 6200007690 S.COL LQW2BHN18NJ03L
6200007700 S.COL LQW2BHN22NJ03L
PARTS LIST
H/V
M.
LOCATION
B 51.8/19
T 68.9/21
T 38.3/35.7
T 29.7/11.6
T 15.9/34.6
T 29.2/34.6
T 40.3/15.2
B 84.2/14.2
T 22.9/34.6
T 89.3/13.2
T 12.5/14.3
T 6.6/5.9
B 16/11.6
T 75/39.6
B 76.8/37.9
B 66.2/37.9
B 51.4/23.1
T 74.3/33.5
T 72.5/19.1
T 82.6/27
T 76.1/27.5
T 67/30.3
T 59.4/36.3
B 56.3/37
T 59/31.5
T 54.9/30.7
T 54.2/37.1
B 56.5/32.6
B 59.1/32.6
T 55.5/44.1
B 51.5/40.4
T 43.3/29.9
T 71.9/16.4
T 24.9/25.9
T 81/15.2
T 76.3/15.1
T 75.7/11.7
T 49.7/18.4
T 24.8/16.7
B 63.1/10.6
B 35.7/9.2
T 91.9/8.6
T 91.4/5.2
T 16.5/23.1
T 19.9/22.5
T 10.7/30.1
T 9.1/26.6
B 90.2/38.7
B 91.5/31.1
B 87.5/33.5
B 87.5/34.8
B 87.4/36.7
B 85/39.9
B 81.8/33.5
B 81.8/34.8
B 73.6/35.9
B 72.2/35.9
T 65.8/35.3
T 65.8/36.7
T 52.6/38.9
T 49.4/28.3
B 49.6/26.9
T 50.5/33.7
T 50.5/35.2
T 41.5/39.2
T 70.5/40.4
B 35.7/7.1
B 21.3/6
B 8.5/11.2
B 23.1/4
T 88.5/36.2
[High band] only B 74.5/19.9
B 62.8/27.1
B 81.2/17.8
T 54.4/20
T 36.9/28.9
B 12/5.9
B 94.7/36.4
B 94.8/31.9
B 92.9/26.3
B 89.9/20.6
B 89.1/36.5
[Low band] B 89.1/36.5
[High band] B 84.3/34.5
[Low band] B 84.3/34.5
[High band] B 78.9/35.3
[Low band] B 78.9/35.3
6 - 1
[MAIN UNIT] (For other than F26-L)
REF PARTS
NO. NO.
L9 6200007670 S.COL LQW2BHN10NJ03L
6200007680 S.COL LQW2BHN12NJ03L
L11 6200007230 S.COL LQW2BHN15NJ03L
6200007680 S.COL LQW2BHN12NJ03L
L12 6200005720 S.COL ELJRE 33NG-F
L13 6200007850 S.COL ELJNC R82K-F
L15 6200002850 S.COL NL 252018T-R82J
L15 6200002851 S.COL NLV25T-R82J
L17 6200012980 S.COL 0.40-1.4-5TR 18.3N
L19 6200005670 S.COL ELJRE 12NG-F
L20 6200005691 S.COL ELJRE 18NGFA
L21 6200007881 S.COL ELJRF 33NJFB
L22 6200007901 S.COL ELJRF 22NJFB
L23 6200002850 S.COL NL 252018T-R82J
L23 6200002851 S.COL NLV25T-R82J
L25 6200008490 S.COL 0.30-0.9-3TR 7.5N
L25 6200012390 S.COL 0.30-0.92-3TR 5.8N <COMO>
L26 6200008510 S.COL 0.30-0.9-4TR 10.5N
L26 6200012970 S.COL 0.30-0.91-4TR 8.6N <COMO>
L27 6200004950 S.COL NL 252018T-1R8J
L27 6200004951 S.COL NLV25T-1R8J
L28 6200004950 S.COL NL 252018T-1R8J
L28 6200004951 S.COL NLV25T-1R8J
L29 6200004660 S.COL MLF1608A 1R8K-T
L30 6200007880 S.COL ELJRF 33NJF2 (33)
L30 6200007881 S.COL ELJRF 33NJFB
L32 6200007910 S.COL ELJRF 18NJF2 (18)
L32 6200007911 S.COL ELJRF 18NJFB
L33 6200004480 S.COL MLF1608D R82K-T
L35 6200003540 S.COL MLF1608D R22K-T
L38 6200005710 S.COL ELJRE 27NG-F
L38 6200005711 S.COL ELJRE 27NGFA
L40 6200002850 S.COL NL 252018T-R82J
L40 6200002851 S.COL NLV25T-R82J
L41 6200007880 S.COL ELJRF 33NJF2 (33)
L41 6200007881 S.COL ELJRF 33NJFB
L42 6200004951 S.COL NLV25T-1R8J
L43 6200004951 S.COL NLV25T-1R8J
L45 6200012490 S.COL 0.30-0.9-6TR 13.6N <COMO>
R1 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k)
R2 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R3 7030004970 S.RES ERJ2GEJ 470 X (47) [Low band]
7030005570 S.RES ERJ2GEJ 820 X (82) [High band]
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k) [Low band] T
7030005220 S.RES ERJ2GEJ 223 X (22 k) [High band] T
R6 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R7 7030005310 S.RES ERJ2GEJ 124 X (120 k)
R8 7030005100 S.RES ERJ2GEJ 154 X (150 k)
7030005170 S.RES ERJ2GEJ 474 X (470 k)
R9 7030008280 S.RES ERJ2GEJ 271 X (270)
R10 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R11 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R12 7030005530 S.RES ERJ2GEJ 100 X (10)
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R14 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R15 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R16 7030004980 S.RES ERJ2GEJ 101 X (100)
R17 7030004970 S.RES ERJ2GEJ 470 X (47)
R18 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R19 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R20 7030005120 S.RES ERJ2GEJ 102 X (1 k) [Low band]
7030005240 S.RES ERJ2GEJ 473 X (47 k) [High band] B
R21 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R22 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R23 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R24 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R25 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R26 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R27 7030005310 S.RES ERJ2GEJ 124 X (120 k)
R28 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R29 7030004980 S.RES ERJ2GEJ 101 X (100)
R30 7030005000 S.RES ERJ2GEJ 471 X (470)
R31 7030004980 S.RES ERJ2GEJ 101 X (100)
R32 7030004980 S.RES ERJ2GEJ 101 X (100)
R33 7030007270 S.RES ERJ2GEJ 151 X (150)
R34 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R35 7030004980 S.RES ERJ2GEJ 101 X (100)
R36 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
R37 7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R39 7030004970 S.RES ERJ2GEJ 470 X (47)
R40 7030007270 S.RES ERJ2GEJ 151 X (150)
R43 7030004970 S.RES ERJ2GEJ 470 X (47)
R44 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R45 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R46 7030005000 S.RES ERJ2GEJ 471 X (470)
R48 7030005000 S.RES ERJ2GEJ 471 X (470)
R50 7030004980 S.RES ERJ2GEJ 101 X (100)
R51 7030003670 S.RES ERJ3GEYJ 823 V (82 k)
R52 7030004990 S.RES ERJ2GEJ 221 X (220)
R53 7030005530 S.RES ERJ2GEJ 100 X (10) [Low band]
7030005710 S.RES ERJ2GEJ 121 X (120) [High band] T
R54 7030005060 S.RES ERJ2GEJ 333 X (33 k)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
[High band] B 75.9/35.2
[Low band] B 75.9/35.2
[Low band] B 70.6/37.8
[High band] B 70.6/37.8
[Low band] only B
B 66.8/33.9
T 93.8/31.8
T 93.8/31.8
B 81.2/20.9
[Low band] only T
T 68.8/33.1
T 59.2/38.6
T 59.5/33.3
T 55.2/28.1
T 55.2/28.1
T 49.5/29.9
T 49.5/29.9
T
T
B
B
B
B
T 43.9/36.4
B 85.1/38.7
B 85.1/38.7
B 55.9/42.3
B 55.9/42.3
T 43.4/25.9
T 41.7/31.8
B 65.6/40.7
B 65.6/40.7
T 53.6/34.6
T 53.6/34.6
B 58.4/38.2
B 58.4/38.2
B
B 49.4/31.1
B 94.9/39.6
B 91.8/39.9
B 92.1/37.7
T 66.7/22.7
T 66.7/22.7
T 75.8/20.8
73.3/21.1
73.3/21.1
T 66.7/18.2
T
[High band] T 71.3/21.1
[Low band] T 71.3/21.1
T 71.3/22.4
T
T 85.5/36.7
T 77.5/37.5
T 82.3/35.7
T 83.9/36.7
B
B 74.8/39.9
B
T 78.8/36.7
T 78.8/38.7
B 75.9/33.6
75.9/33.6
T 72.2/38.9
T 69.2/38.9
T 71.2/38.9
T
B
B 64.2/38.1
B 62.5/38.1
B 62.5/40.8
B 64.2/35.1
B 67.7/35.7
B 64.2/32.1
B 66.1/31.1
B 55.5/25.2
B 52.5/25.2
B 50.5/25.2
T 52.5/15.5
T 50.7/16.3
T
B 55.8/22.3
B 56.2/21.1
B 47.5/15.4
B 54.8/15.4
B 52.8/13.7
B 53.8/13.7
B 51.5/25.2
T
B 96.5/37.3
T 93.3/35.9
T
T 81.3/21.4
S.=Surface mount
H/V
64.2/39
76/35.5
49/37.9
49/37.9
52.8/29
52.8/29
52/36.6
52/36.6
49.4/34
68/17.7
68.4/24
79.1/39
74/33.3
64.6/38
68/37.8
46.5/21
66.3/38
80/22.5
80/22.5
