SECTION 5
SECTION 5
■ ASSEMBLED CHASSIS UNIT
Spare unit name
U F2000 #11 CHASSIS
See the illustrations below for the individual parts in the unit.
<Front view>
ANT CONNECTOR 106
<Back view>
SPARE PARTS AND UNITS
SPARE PARTS AND UNITS
Order Number
0341121103
J1
MP44
PHBT M2 × 4 NI-ZC3
(Securing the antenna connector)
Applicable Versions
#11~#19, #21, #23~#25,
#35~#40, #42~#44, #48~#50
MP1
3621 CHASSIS
MP51
THERMAL SHEET (CJ)
MP30
3621 SPONGE
MP1
3621 CHASSIS
5-1
Remarks
‒
MP50
THERMAL SHEET (CQ)
MP15
2905 VENT SHEET
MP46
3254 H-LABEL
