• MAIN CPU (MAIN UNIT: IC300)
Ball
Line Name
No.
A4
R_LV
Lock voltage input. (Band B)
A6
VIN
External power supply voltage.
WX alert signal (1050 Hz). (Band
A7
L_WXALT
A)
The [UP]/[DOWN] key input from
A8
MICUD
the microphone.
Response signal from the audio
A9
AUDI
IC.
5VS power supply line control.
A11
PSC
L= While in the power save mode.
A12
DA_STB
D/A converter serial strobe.
DTMF tone, European tone and
B1
DTMF
beep sound signals.
B4
R_RSSI
RSSI voltage. (Band B)
B7
IDET
Transmit current sensing voltage.
Transceiver temperature sensing
B8
TEMP
voltage.
Audio IC reset.
B9
AURES
L=Reset.
TSQL/DTCS tone fi lter switching
C2
DTCS
control.
H= While the DTCS tone is used.
TSQL/DTCS tone signal. (Band
C4
R_DTCSIN
B)
TSQL/DTCS tone signal. (Band
C7
L_DTCSIN
A)
Tone
C9
DTMUTE
ETONE) modulation mute.
L=Mute.
DSP power down control.
C11
DSP_PD
H= Power down.
D1
DA_DATA
Serial data to the D/A converter.
Serial data from the Bluetooth
D2
BTRXD
unit.
Weather alert signal (1050 Hz)
D4
R_WXALT
detect. (Band B)
D5
R_LV
Lock voltage. (Band B)
D6
VOX
VOX sensing voltage.
D7
L_RSSI
RSSI voltage. (Band A)
D8
AUSTB
Audio IC serial strobe.
D11
DA_CK
Serial clock to the D/A converter.
E4
BTTXD
Serial data to the Bluetooth
CPU reset signal.
G1
RESET
L=Reset.
Bluetooth
G3
BT_RES
H=Reset.
G4
MIC_PTT
PTT input from the microphone.
Serial clock to the sub CPU
H14
SCSCK
(IC303).
Serial data from the sub CPU
H15
SCRXD
(IC303).
Interrupt detection from the real
J4
RTC_IRQ
time clock IC.
L= Alerm detected.
The [RWD] key input from the Blu-
J12
BWD
etooth
L=When pushed.
The [PLAY] key input from the Blu-
J13
BTPLAY
etooth
L=When pushed.
Description
signal
(BEEP/DTMF/
®
®
unit. O
®
unit reset signal.
®
unit.
®
unit.
Ball
I/O
Line Name
No.
I
I
J15
BT_SW
I
K1
L_SQL
I
K3
IOSTB
I
K14
FWD
O
K15
IOEN
O
M1
98_DATA
O
I
M2
TX_DATA
I
M5
DSP_STB
M7
ECK
I
M8
L_UNLK
O
M9
VOL_DATA
O
M12
TX232
I
N1
RX_DATA
I
N2
SD_SENC
N3
SD_TXD
O
N4
DSP_SI
N5
CLIN
O
O
N6
RTC_SDA
I
N7
ESIO
N9
VOL_CK
I
I
N12
DATA
I
I
N13
SCTXD
O
P1
SD_CS
O
P2
SD_SCK
R8
R_UNLK
I
K4
DSP_REQ DSP "REQEST" signal.
O
P4
DSP_CK
P5
PDV
I
O
P6
H_PTT
I
P7
SD_SW
I
P10
SCACK
P12
BTUNIT
I
P13
RX232
R1
SD_RXD
I
R2
DSP_SO
4-7
Description
®
Bluetooth
unit power supply con-
trol.
®
H= The Bluetooth
unit is acti-
vated.
Noise level detection. (Band A)
H= Noise signal is detected.
Expander serial strobe.
The [FWD] key input from the Blu-
®
etooth
unit.
L=When pushed.
Expander chip enable.
Control serial data from the micro-
phone.
Control serial data to the CPU on
the CONTROL UNIT.
DSP serial strobe.
EEPROM serial clock.
PLL unlock detection. (Band A)
L=Unlocked.
Serial data to the audio volume
IC.
UART data (RS-232C).
(4800/9600/38400 bps)
Control serial data from the CPU
on the CONTROL UNIT.
SD card insert detection.
L=Inserted.
Serial data to the SD card.
DSP serial data.
CI-V/CLONE UART data.
(300–38400 bps)
Serial data to/from the real time
clock IC.
EEPROM serial data.
Serial clock to the audio volume
IC.
Common serial clock to the D/A
converter and expander.
Serial data to the sub CPU
(IC303).
Chip select to the SD card.
Serial clock to the SD card.
PLL unlock detection. (Band B)
L=Unlocked.
DSP serial clock.
Power supply voltage drop detect.
[PTT] input from the Bluetooth
unit.
L=Pushed.
SD card driver power supply con-
trol.
H=SD card driver is activated.
"ACK" signal from the sub CPU.
®
Bluetooth
unit mount detect.
L=Mounted.
RS-232C UART data.
(4800/9600 bps)
Serial data from the SD card.
DSP serial data.
I/O
O
I
O
I
O
I
O
O
O
I
O
O
I
I
O
I
I
I/O
I/O
O
O
O
O
O
I
I
O
I
®
I
O
I
I
I
I
O
