PCI-QUAD-AC5 User's Guide
Connecting the board for I/O operations
Connectors, cables – main I/O connector
Table 2-1
lists the board connectors, applicable cables, and compatible accessory products for the PCI-
QUAD-AC5.
Table 2-1. Board connector, cables, and accessory equipment
Connector type
Compatible cables
Compatible accessory products (with
the C50FE-x cable)
Compatible accessory products (with
the C50FF-x cable)
The PCI-QUAD-AC5 has four 50-pin header connectors (P1 to P4). If you are connecting to SSR-PB24
racks or equivalent, we recommend using the C50FE-x series cable (see
If you need direct access to the digital I/O, use the C50FF-x series cable to connect four CIO-MINI50
boards, four CIO-SPADE50, two SCB-50 boards, or two CIO-TERM100 terminal accessory boards. Any
of these bring all I/O connections out to convenient, easy-to-use screw terminals.
When installing the ribbon cables, thread them through the bracket on the end of the board.
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections (available at www.mccdaq.com/signals/signals.pdf).
Pinout – main I/O connectors
The pin out for the four I/O connectors is listed in Fi
Four, male 50-pin 0.1" spaced double row connectors
C50FE-x cable
C50FF-x cable
SSR-PB24 (up to 4, one cable required per PB24 board)
CIO-MINI50 (four)
CIO-SPADE50 (four)
CIO-TERM100 (two)
SCB-50 (two)
gure 2-1
.
2-4
Installing the PCI-QUAD-AC5
Figure 2-2
).
