Specifications

Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.

Power consumption

+5V

Digital input / output

Digital type
Number of I/O
Configuration per 82C55A Mode 0
emulation
Input low voltage
Input high voltage
Output low voltage
Output high voltage
High level output current
Low level output current
Absolute maximum input voltage
Pull-up/pull-down resistors
Power on / reset

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products (with the
C50FE-x cable)
Compatible accessory products (with the
C50FF-x cable)
2.4 A typical, 3.6 A max
Digital Outputs - 74S244
Digital Inputs - 74LS373
96
2 banks of 8 bits and 2 banks of 4
Each bank programmable as either input or output
0.8 V max.
2.0 V min.
0.5 V max. (Iol = 64 mA)
2.4 V min. (Ioh = -15 mA)
-15 mA max.
64 mA max.
7.0 V max.
Locations provided for user installation of pull-up or pull-down
resistors.
High impedance
0 to 70 °C
-40 to 70 °C
0 to 95% non-condensing
PCI long card: 312 mm long x 107 mm high x 18.5 mm thick
Four, male 50-pin 0.1" spaced double row connectors
C50FE-x cable
C50FF-x cable
SSR-PB24 (up to 4, one cable required per PB24 board)
CIO-MINI50 (four)
CIO-SPADE50 (four)
CIO-TERM100 (two)
SCB-50 (two)
