PCI-QUAD-AC5 User's Guide
P3
Pin Signal Name
1 THIRD PORT C Bit 7
3 THIRD PORT C Bit 6
5 THIRD PORT C Bit 5
7 THIRD PORT C Bit 4
9 THIRD PORT C Bit 3
11 THIRD PORT C Bit 2
13 THIRD PORT C Bit 1
15 THIRD PORT C Bit 0
17 THIRD PORT B Bit 7
19 THIRD PORT B Bit 6
21 THIRD PORT B Bit 5
23 THIRD PORT B Bit 4
25 THIRD PORT B Bit 3
27 THIRD PORT B Bit 2
29 THIRD PORT B Bit 1
31 THIRD PORT B Bit 0
33 THIRD PORT A Bit 7
35 THIRD PORT A Bit 6
37 THIRD PORT A Bit 5
39 THIRD PORT A Bit 4
41 THIRD PORT A Bit 3
43 THIRD PORT A Bit 2
45 THIRD PORT A Bit 1
47 THIRD PORT A Bit 0
49 +5V Out
P4
Pin Signal Name
1 FOURTH PORT C Bit 7
3 FOURTH PORT C Bit 6
5 FOURTH PORT C Bit 5
7 FOURTH PORT C Bit 4
9 FOURTH PORT C Bit 3
11 FOURTH PORT C Bit 2
13 FOURTH PORT C Bit 1
15 FOURTH PORT C Bit 0
17 FOURTH PORT B Bit 7
19 FOURTH PORT B Bit 6
21 FOURTH PORT B Bit 5
23 FOURTH PORT B Bit 4
25 FOURTH PORT B Bit 3
27 FOURTH PORT B Bit 2
29 FOURTH PORT B Bit 1
31 FOURTH PORT B Bit 0
33 FOURTH PORT A Bit 7
35 FOURTH PORT A Bit 6
37 FOURTH PORT A Bit 5
39 FOURTH PORT A Bit 4
41 FOURTH PORT A Bit 3
43 FOURTH PORT A Bit 2
45 FOURTH PORT A Bit 1
47 FOURTH PORT A Bit 0
49 +5V Out
Pin Signal Name
2 GND
4 GND
6 GND
8 GND
10 GND
12 GND
14 GND
16 GND
18 GND
20 GND
22 GND
24 GND
26 GND
28 GND
20 GND
32 GND
34 GND
36 GND
38 GND
40 GND
42 GND
44 GND
46 GND
48 GND
50 GND
Pin Signal Name
2 GND
4 GND
6 GND
8 GND
10 GND
12 GND
14 GND
16 GND
18 GND
20 GND
22 GND
24 GND
26 GND
28 GND
20 GND
32 GND
34 GND
36 GND
38 GND
40 GND
42 GND
44 GND
46 GND
48 GND
50 GND
5-3
Specifications
