CDM-740 Advanced Satellite Modem
Remote Control
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
SNMP SSL= 254 bytes,
System characters,
Location
SNMP SSN= 16 bytes,
Unit Name characters,
SNMP Trap STA= 15 bytes,
Destination IP Numerical
Address
SNMP SWC= 16 bytes,
Write characters, no
Community spaces
Tx BERT TBP= 1 byte
Pattern
Modem Time TIM= 6 bytes
Unit Test TST= 1 byte, value of
Mode 0 thru 2
Description of Arguments
Command or Query.
SNMP System Location string
Example: <1/SSL=Upstairs back right
If not configured it returns empty string: <1/SSL=
Command or Query.
SNMP System Name string
Example: <1/SSN=Remote1.
If not configured it returns empty string: <1/SSC=
Command or Query.
Sets or returns the IP address of the SNMP Trap destination IP Address
where traps are sent, in the form xxx.xxx.xxx.xxx where:
xxx.xxx.xxx.xxx is the IP addresss
Example: <1/STA=010.006.030.001
Returns >0001/STA=0.0.0.0 when not configured.
Command or Query.
SNMP write community string. Empty string is not allowed
Example: <1/SWC =public
Command or Query.
Tx BERT Pattern, where:
0=2^23-1 (default)
1=2047
Example: TBP=1 (Tx BERT Pattern is 2047)
Command or Query.
A time in the form hhmmss, indicating the time from midnight, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours,12 minutes, 59 seconds)
Command or Query.
Unit Test Mode, where:
0=Normal Mode (no test)
1=Tx CW
2=Tx Alternating 1,0 Pattern
Example: TST=1 (Tx CW)
A–18
MN-CDM740
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
SSL = SSL? SSL =x [1..254]
SSL! (see Description of
Arguments)
SSN = SSN? SSN =x [1..16]
SSN! (see Description of
Arguments)
STA = STA? STA = xx.xxx.xxx.xxx
STA! (see Description of
Arguments)
SWC = SWC? SWC =x
SWC! (see Description of
Arguments)
TBP= TBP? TBP=x
TBP? (see Description of
TBP# Arguments)
TIM= TIM? TIM=hhmmss
TIM? (see Description of
TIM* Arguments)
TIM#
TST= TST? TST=x
TST? (see Description of
Arguments)
TST*
TST#
