D Menu S-1 Functions; D Menu S-2 Functions - Icom IC-7000 Instruction Manual

1
PANEL DESCRIPTION

D Menu S-1 functions

DURING SSB/AM OPERATION:
VO
F-1 F-2
DURING CW OPERATION:
VO KEY MET
F-1 F-2
DURING RTTY OPERATION:
VO DEC
F-1 F-2
DURING FM/WFM OPERATIONS:
VO DTM
F-1 F-2
VO (p. 95)
Push to enter the voice recorder mode.
VO
• The voice TX/RX menu or voice root menu
F-1
appears depending on the "VOICE 1st
Menu" setting in the miscellaneous (others)
set mode. (p. 136)
METER SELECTION (p. 36)
Push to select the type of metering dis-
MET
played (during transmit) on the display.
F-3
• Power, SWR, ALC or COMP metering can be
selected.
• Only an S-meter is available during receive.
VOICE SQUELCH CONTROL (p. 84)
Push to toggle the voice squelch control
VSC
function ON and OFF.
F-4
KEYER OPERATION (p. 45)
Push to enter the memory keyer mode.
KEY
• The keyer send menu or keyer root menu ap-
F-2
pears depending on the "KEYER 1st
Menu" setting in the miscellaneous (others)
set mode.(p. 136)
RTTY DECODER FUNCTION (p. 54)
Push to toggle the RTTY decoder display
DEC
ON and OFF.
F-2
• RTTY decoder screen appears.
7
MET VSC
F-3 F-4
VSC
F-3 F-4
MET VSC
F-3 F-4
MET VSC
F-3 F-4
DTMF OPERATION
Push to enter DTMF memory mode.
DTM
(p. 67)
F-4
• The DTMF send menu or DTMF root menu
appears depending on the "DTMF 1st
Menu" setting in the miscellaneous (others)
set mode. (p. 136)

D Menu S-2 functions

DURING VFO MODE:
SCN PRI
F-1 F-2
DURING MEMORY MODE:
SCN SEL
F-1 F-2
SCAN (pgs. 113–115)
➥ Push momentarily to start or stop the
SCN
scan function.
F-1
PRIORITY WATCH (p. 115)
Push to start or stop priority watch.
PRI
F-2
VFO/MEMORY SELECTION
➥ Push momentarily to toggle VFO and
V/M
memory modes. (pgs. 27, 102)
F-3
➥ Push and hold for 1 sec. to transfer the
frequency and operating mode in the se-
lected memory channel to the currently
displayed VFO. (p. 109)
VOICE SQUELCH CONTROL (p. 84)
Push to toggle the voice squelch control
VSC
function ON and OFF.
F-4
SELECT SCAN
➥ Push momentarily to toggle the select
SEL
scan settings ON and OFF for the se-
F-2
lected memory channel. (pgs. 106, 115)
➥ Push and hold for 2 sec. to clear all select
scan setting. (p. 115)
➥ While scanning, push to toggle the se-
lected memory scan ON and OFF.
(p. 115)
V/M VSC
F-3 F-4
V/M VSC
F-3 F-4
