Figure 6. Position of the Rack Installation Stencil (Rear View)

REAR VIEW

Figure 7. Aligning of the Rack Installation Stencils for systems with more than two units

26
NOTE: Single hole
facing downwards,
double hole facing
upwards
Align holes, overlap stencils
Align holes, overlap stencils
Hardware Installation
