Chapter 10 Options

Memory Card

Adapter, cont.
Important!
The printer must be OFF when
the memory card is inserted or
removed.
Memory Card
98
Fitting a Memory Card
• Switch off the power to the printer and open the front door.
• In case of non DOS-formatted memory card, check that the
protection switch is set to Write Protect. (The location of the
switch varies between different brands.) This does not apply to
DOS-formatted memory cards!
• Insert the memory card into its adapter as illustrated below.
Make sure that the manufacturer's logotype on the memory
card is facing upwards.
• Press fi rmly inwards so the pins in the adapter engage the
corresponding slots in the memory card.
• Switch on the power again and close the front door.
Removing a Memory Card
• Before removing the memory card, switch off the power.
• Open the front door and pull the card straight out.
• Close the front door and switch on the power again.
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
Protection Switch
