Internal Batch
Takeup
1
Open the front and side doors.
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
The EasyCoder 501 E printers can print on labels, tickets, tags,
and continuous stock in various forms. This chapter describes
the case when printed labels fitted on liner (backing paper) or
pre-perforated tickets and tags are wound up inside the printer. The
roll of printed labels, tickets, or tags can then be removed and be
handled manually. This requires an optional internal liner takeup
unit and a batch takeup guide.
The takeup hub can accommodate
roll.
Internal batch takeup can be used for:
• Self-adhesive labels fi tted on liner
• Preperforated tickets with gaps
• Preperforated tickets with marks
2
Turn the printhead lift lever to "Load" posi-
Chapter 5 Media Load
1 1
/ to / of a full-size media
4 3
tion.
41
