Terminal Setup, cont.

Setup Parameters

Note:
After you have pressed CR, a series of
additional prompts will appear where
you can adjust the LSS following the
same principles as described in Chapter
13 "Adjustments".
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
The displayed values refer to the default setup of an 8 dots/mm
EasyCoder 501 E without any optional interface board.
----------------
SETUP FROM
TERMINAL
----------------
Reading printer setup, please wait.
If no change, press ENTER
To end terminal setup: enter QUIT (Q), or QUIT and SAVE (S)
CONTRAST,5
New value: (0-10) :
UART1,BAUDRATE,9600
New value: (1:300 2:600 3:1200 4:2400 5:4800 6:9600 7:19200) :
UART1,PARITY,NONE
New value: (1:NONE 2:EVEN 3:ODD 4:MARK 5:SPACE) :
UART1,CHAR LENGTH,7
New value: (1:7 2:8) :
UART1,STOPBITS,2
New value: (1:1 2:2) :
UART1,FLOWCONTROL,RTS/CTS,DISABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,ENQ/ACK,DISABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,XON/XOFF,DATA FROM HOST,ENABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,FLOWCONTROL,XON/XOFF,DATA TO HOST,ENABLE
New value: (1:ENABLE 2:DISABLE) :
UART1,NEW LINE,CR/LF
New value: (1:CR/LF 2:LF 3:CR) :
DETECTION,LSS ADJUST,80
New value: (0-127) Press F <CR> for testfeed. Press <CR> when OK :
DETECTION,FEEDADJ,STARTADJ,0
New value: (-9999 thru +9999) :
DETECTION,FEEDADJ,STOPADJ,0
New value: (-9999 thru +9999) :
MEDIA SIZE,XSTART,0
New value: (0-999) :
MEDIA SIZE,WIDTH,832
New value: (0-9999) :
MEDIA SIZE,LENGTH,1200
New value: (0-9999) :
MEDIA TYPE,LABEL (w GAPS)
New value: (1:LABEL (w GAPS) 2:TICKET (w MARK) 3:TICKET (w GAPS))
(4:FIX LENGTH STRIP 5:VAR LENGTH STRIP) :
