Memory Card

Switching On

Intermec EasyCoder F4 – Installation & Operation Ed. 3
If you want to use a memory card, you must insert it into the slot
in the printer's rear plate before you switch on the power. The
memory card can be an SRAM card complying with the JEIDA-4
standard or a Flash Memory card from Intermec. Maximum size
in both cases is 64Mbit (8MB). There are three types of Flash
Memory cards:
• Font Cards provide additional fonts that can be used as long as
the card remains inserted in the printer.
• Font Install Cards permanently install additional fonts, which can
be used even after the card has been removed.
• Firmware Cards automatically replace the printer's fi rmware,
usually with an updated version.
Always switch off the power before inserting or removing a
memory card! The manufacturer's logotype should face right
when viewing the card as in the illustration above.
Before switching on the printer, make the necessary connections,
insert any memory card you want to use, and check that the
printhead is engaged.
Switch on the power using the On/Off switch on the rear plate. The
"Power" control lamp on the front panel lights up when the power is
on. Wait for a few moments, while the printer loads the program and
runs some self-diagnostic tests. Then a message will appear in the
display window, depending on the startup fi le.
Chapter 4
Important!
Starting Up
Memory Card
27
