Peel-Off, cont.
10
Pull out approximately 40 cm (15 inches) of
labels and peel off the labels manually from
12
Secure the liner to the takeup hub with the clip
(1) and wind up some of the liner so it becomes
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
the liner.
2.
tight (2).
11
Route the liner around the platen roller and
the tear bar, then rearwards under the print
13
1.
Turn the printhead lift lever to "Print" posi-
Chapter 5 Media Load
unit.
tion.
