Chapter 13 Adjustments
Display Contrast
122
The contrast of the printer's display can be adjusted using a
potentiometer, which is situated close to the connector of "uart1:".
It can be accessed through a small hole in the rear plate. Using
a narrow-tipped screwdriver, turn the screw in either direction
until the text in the LCD display on the printer's front becomes
clearly visible in the prevailing light conditions when viewed from
a normal working position.
Display Contrast Adjustment
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
