Setup Parameters, cont.
Service, cont.
Bar Code Directions
Horizontal
(Picket Fence)
Vertical
(Ladder)
Feed
Direction
Intermec EasyCoder 501 E – Installation & Operation Ed. 1

Performance

The Performance setup parameter allows you to decide the print
speed. Three options are displayed: Normal (default), High, and
Ultra High. These options translate to different nominal print
speeds depending on printhead density, type of printing, and type of
supplies as illustrated by the tables below. Supplies, which have been
specifi ed using the "New Supplies" option, have fi xed print speed
settings that overrides the "Performance" setup.
Printhead density 8 dots/mm (203.2 dpi)
Thermal Transfer Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 200 mm/sec (8 in/sec) 200 mm/sec (8 in/sec) 100 mm/sec (4 in/sec)
Ultra High 200 mm/sec (8 in/sec) 200 mm/sec (8 in/sec) 200 mm/sec (8 in/sec)
Thermal Transfer Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
Ultra High 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
Direct Thermal Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 150 mm/sec (6 in/sec) 150 mm/sec (6 in/sec) 100 mm/sec (4 in/sec)
Ultra High 150 mm/sec (6 in/sec) 150 mm/sec (6 in/sec) 150 mm/sec (6 in/sec)
Printhead density 11.81 dots/mm (300 dpi)
Thermal Transfer Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec) 100 mm/sec (4 in/sec)
Ultra High 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec)
Thermal Transfer Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
Ultra High 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
Direct Thermal Printing
Performance Text Printing
Normal 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec) 100 mm/sec (4 in/sec)
High 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec) 100 mm/sec (4 in/sec)
Ultra High 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec) 125 mm/sec (5 in/sec)
Chapter 7 Setting Up the Printer
GP/Standard & HP/Premium Ribbons
Hor. Bar Code Vert. Bar Code
HR/Super Premium Ribbons
Hor. Bar Code Vert. Bar Code
Hor. Bar Code Vert. Bar Code
GP/Standard & HP/Premium Ribbons
Hor. Bar Code Vert. Bar Code
HR/Super Premium Ribbons
Hor. Bar Code Vert. Bar Code
Hor. Bar Code Vert. Bar Code
