Default Setup

Contrast
Ser-Com ("uart1:")
Detection
Service
Reading the
Current Setup
Intermec EasyCoder 501 E – Installation & Operation Ed. 1
The printer's default setup with standard confi guration EPROMs
is listed below:
Baud rate:
Parity:
Character length:
Stop bits:
RTS/CTS:
ENQ/ACK:
XON/XOFF, data to host:
XON/XOFF, data from host:
New line:
Feedadjust:
Startadjust:
Stopadjust:
Media Size:
X-start (8 /11.81 dots per mm):
Width (8 /11.81 dots per mm):
Length (8 /11.81 dots per mm):
Media type:
Print defs:
Paper type (thermal transfer printers): UBI HP 20
Paper type (direct thermal printers):
Performance:
Memory alloc:
Image buffer size:
Receive buffer:
Transmit buffer:
The printer's current setup values can be read from the printer's
display window by browsing through the Setup Mode, or from the
host by browsing through the Terminal Setup of Intermec Shell.
You can list the printer's current setup values by printing test label
#5 in the Setup Mode or by using Intermec Shell. The current setup
values can be sent to the host via the standard serial communication
channel using a SETUP WRITE "uart1:" statement (see Intermec
Fingerprint v6.14, Reference Manual).
Chapter 7 Setting Up the Printer
Middle (5)
9600
none
7 bits
2 bits
Disable
Disable
Enable
Enable
CR/LF
0
0
0/0
832/1280
1200/1200
Label (w Gaps)
RICOH 130LAB/LAM
Normal
48 Kbytes
300 bytes
300 bytes
