HP Pro 2110 Small Form Factor Maintenance & Service Manual page 77

Figure 5-20
System Board Drive Connections – HP Pro 3130
Table 5-7 System Board Drive Connections – HP Pro 3130
No. System Board Connector
1 SATA1
2 SATA2
3 SATA3
4 SATA4
5 Media Card Reader
System Board Label
SATA1
SATA2
SATA3
SATA4
JUSB1
Color
dark blue
white
light blue
orange
white
Drives 67
