Scan Upper Assembly - Muratec F-110 Field Engineering Manual

6-8 Scan Upper Assembly

0
S
4
Scan Upper Assembly Parts List
No.
0 ELA HOU-SCAN UPPER
1 MEC-PINCH
2 RPR-SPONGE ADF
3 MPR-TAPE ADF
4 CBF HARNESS-SCAN GND
5 SPRING-SENSOR
6 SPRING-COIL ADF
7 PMO-SCAN UPPER
8 PMO-LEVER SENSOR DOC
9 PMO-LEVER SENSOR
10 ICT-SHAFT PINCH
11 PMO-HOLDER RUBBER
12 PMO-ROLL PINCH
13 PMO-SUPPORT ADF
14 RPR-RUBBER ADF
15 MEC-BRUSH ANTISTATIC
1
Description
10
12
8
9
5
S
15
3
14
11
SEC.Code
JC81-00457A
JG75-10015A
JB73-10913A
JB74-10917A
JC39-00101A
JC61-00018A
JC61-00040A
JC72-00671A
JC72-00823A
JC72-41322A
JF70-40521B
JG72-40044A
JG72-40663A
JG72-41083A
JC73-00032A
JG75-10004A
Exploded View and Parts List
6
2
13
7
S
O : Service available X : Service not available
Q'ty SA
1 O
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
2 X
1 X
1 O
1 X
Remark
6-15
