8. Insert the excess wire into the Console (23) or
the Upright (2).
Press the Rear Upright Cover (75) into the
Upright (2). Have a second person hold the Rear
Upright Cover in place.
Tip: Avoid pinching the wires. Attach the
Console (23) to the Upright (2) with four M4 x
16mm Self-tapping Screws (52).
9. Finish attaching the Left and Right Handlebars
(85, 86) to the Upright (2) with an M8 x 77mm
Bolt (79) and an M8 Locknut (38).
Tip: While inserting the M8 x 77mm Bolt (79),
avoid pinching or damaging the wires inside
the Upright (2).
See step 5. Tighten the M8 x 77mm Bolt (79).
8
23
75
9
38
85
2
9
Avoid pinching
the wires
2
52
Avoid pinching
the wires
79
86
