The 4600 series IP Telephones require the Avaya Application Solutions Circuit packs TN799C
or higher C-LAN board for registration to the gatekeeper and signaling stream, and the
TN2302AP (MedPro) for call setup and media stream. In the case of the G700 Media Gateway,
the VoIP Engine or VoIP Media Module provides the support for media stream.
IP Telephone installations require a Trivial File Transfer Protocol (TFTP) server on the network
for software transfer to the IP Telephones. Avaya strongly recommends DHCP servers. IP
Telephone investment protection is supported by the software download capability. Future
software releases for the telephones that offer feature enhancements or protocol changes are
possible without changing the hardware platform. Software updates are provided as required to
correct bugs, implement changes, and add new features and capabilities.
For customers who want an all switched network, the 4620 telephone contains an integrated
Layer 2 switch. In addition, the 30A Ethernet Switch Base adds fully switched capability to the
4612 and the 4624 telephones.
Features and applications
Table 18: Avaya 4600 series IP Telephone features and applications
Feature
Speakerphone
Infrared capabilities
Speed Dialing
Call Log Application
Application
High-quality, built-in speakerphone with echo cancellation,
directional microphone, and a tuned speaker cavity provides
the highest audio quality.
An infrared data association (IrDA) port is provided on the
front of each IP Telephone for Personal Digital Assistant
(PDA) and PC application integration (not available on 4602
sets). With the built-in IrDA port, users can communicate
with and command the telephone using a personal digital
assistant (PDA) or other infrared-equipped device.
This feature allows the user to store telephone numbers that
are dialed at the touch of a feature button. Users can
program up to 120 speed-dial buttons.
(4620 and 4630 sets only)
This feature stores and displays information, such as
identifying the call as Outgoing, Incoming Answered, and
Incoming Unanswered. It presents information about all calls
in a given category.
Up to 90 entries on 4620 sets
Up to 100 entries on 4630 sets
Avaya 4600 Series IP Telephones
1 of 2
Issue 3.4.1 June 2005
133
