The Station List and Station Map
The Station List window and fields; viewing station statistics; removing a station from the ring; the
Station Map; the Station Command menu; manipulating the Station Map
The Station List window conveniently allows you to view statistics and configure
the stations on the currently monitored ring network.
The Station Map graphically illustrates the ring configuration in downstream
neighbor order from the currently monitored MicroMMAC-T, and provides
address information for individual stations inserted into the ring.
Both windows also allow you to access statistics, timer statistics, and performance
graphs for each inserted ring station (including the MicroMMAC-T's onboard
management station), and also remove stations from the ring.
You can also set alarm limits for individual stations through the Station List and
Station Map windows.

The Station List Window

At the MicroMMAC-T Station List window
station on the ring network supported by the MicroMMAC-T (including stations
physically attached to another device that are on the ring) in ring order starting
from the MicroMMAC-T's management station. Using this window, you can view
statistics for each station on the monitored ring, as well as temporarily remove a
station port from the ring network, and set alarm limits for individual stations.
To access the Station List window, select Station List... from the Network menu
on the MicroMMAC-T Chassis View window.
Chapter 5
(Figure 5-1), you can view each
5-1
