The MicroMMAC-T Chassis View
Port status view options are:
Load
If you choose Load, the port text boxes will display the percentage of network
load processed by each port during the last polling interval. This percentage
reflects the network load generated by devices connected to the port compared to
the theoretical maximum load (4 or 16 Mbits/sec) of a Token Ring network.
Status
You can view two Status categories for your ports which reflect six possible
Admin/Link or Admin status conditions:
•
•
If you have selected the Admin/Link status mode, a port is considered:
•
•
•
•
If you have selected the Admin status mode, a port is considered:
•
•
Errors
If you choose the Errors mode, an additional menu offers the following options:
Errors
The port status boxes will display the percentage for each active port that
represents what portion of that port's total traffic is of the specific error type that
you selected. See Chapter 3, Token Ring Statistics, for complete descriptions of
these error types.
Select one of the Errors options to see what percentage of the total frames received
by each active port during the last polling interval was of the error type you
selected. This percentage reflects the number of errors generated by devices
connected to that port in relation to the total number of frames processed by the
port (errors ÷ [errors + frames]).
2-10
Admin/Link — ENB (enabled), BYP (bypassed), LNK (linked), or INS
(inserted)
Admin — ON or OFF
ENB (enabled) if the port has been enabled by management, but there is no
station linked to that port.
BYP (bypassed) if the port has been disabled by management, and there is no
station linked to that port.
LNK (linked) when the port has been disabled by management, and there is a
station linked to that port.
INS (inserted) when the port has been enabled by management, and there is a
station linked to that port.
ON if the port is enabled.
OFF if the port has been disabled by management.
Total Soft Errors, Line, Burst, AC, Abort Sequences,
Internal, Lost Frames, Congestion, FC, Token, or
Frequency
Viewing Chassis Information
