The MicroMMAC-T Chassis View
station list, and transmit a Remove Ring Station MAC frame to the offending
station. This option is enabled by default.
This feature is available for devices running firmware versions 3.00.09 and later only.
NOTE

Viewing Network Information

At the Network Information window
configuration information for each ring in your MicroMMAC-T-controlled hub.
You can identify each ring by name using the Network Name field.
To access the Network Information window:
1. At the MicroMMAC-T Chassis View window, click on the Network menu
2. Click on Network Info.... The Network Information window will appear.

Selecting the Ring

If there is more than one ring network residing in your hub, you can view
information for each ring by using the Previous and Next buttons. By default, the
rings are identified only by an index number: Ring 1 is the
MicroMMAC-T-managed ring; any additional rings are indexed in ascending
order.
The field to the left of the Previous and Next buttons displays the selected ring in
terms of total rings currently supported on the hub, in X (current ring) of X
(configured rings) format.
To view the next ring in sequence, click on the Next button. When you have
reached the last available ring, the Next button will be grayed out to indicate that
no more rings are available.
To return to a prior ring, click on the Previous button. The Previous button will be
grayed out when you reach the first ring detected by the MicroMMAC-T.
2-18
selection, then on the Network 1 entry to display the Network menu
selections.
(Figure 2-9), you can view status and
Managing the Hub
