Using the Pie and Bar Radio Buttons

You can use the Pie and Bar radio buttons to switch from bar graph to pie chart.
With the pie chart or bar graph, you can view the traffic, broken into protocols,
that is passing through the MicroMMAC-T. Both graphs will reflect the type of
collection you have chosen: Total or Delta.
To display a pie chart or bar graph:
1. Click on the Pie or Bar radio button. The Pie chart or the Bar graph, as you

Management Station Statistics

Through the Device menu, you can view network statistics for the
MicroMMAC-T's on board ring management station.

Accessing the Management Station Statistics Selection

To access the Intelligent Module pull-down menu from the MicroMMAC-T
Chassis View window:
1. Click on the Device menu selection on the menu bar in the MicroMMAC-T
2. Click to highlight the Mgmt. Station Statistics... selection. The TR
The upper left corner of the The TR Management Station Statistics window
(Figure
The window also lists the current ring speed set at the device.
Management Station Statistics
Click on the Total radio button. The window will now display the total count
of protocol types processed since the most recent start-up of the
MicroMMAC-T. The dynamic bar graph or pie chart to the right of the
numbers reflects counts processed since the last start-up.
have selected, will appear on the window.
Chassis View. The Device menu will appear.
Management Station Statistics window will appear.
3-10) contains the module's name, location, and MAC and IP addresses.
Token Ring Statistics
3-15
