Introduction
IP Address
Figure 1-2. Sample Window Showing Informational Text Boxes
Device Name
Displays the user-defined name of the device. The device name can be changed
via the System Group window; see the Generic SNMP User's Guide for details.
IP Address
Displays the device's IP (Internet Protocol) Address; this will be the IP address
used to define the device icon. IP addresses are assigned via Local Management
for the MicroMMAC-T; they cannot be changed via NetSight Element Manager.
Location
Displays the user-defined location of the device. The location is entered through
the System Group window; see the Generic SNMP User's Guide for details.
MAC Address
Displays the manufacturer-set MAC address associated with the IP address used
to define the MicroMMAC-T icon. This address is factory-set and cannot be
altered via NetSight Element Manager. The device's MAC address may be altered
using local management; if so, the locally administered MAC address will appear
in this field.
1-6
Device
Name
Location
MAC
Address
