The MicroMMAC-T Chassis View
UPS ID
Displays the manufacturer and model type code of the UPS attached to the
modem port of the MicroMMAC-T. You must assign this type code for the UPS
window to be active. (See
the type code for your UPS.) The valid type codes are:
•
•
•
•
•
•
UPS Uptime
Displays the number of hours that the UPS has been operating since the last time
it was started up.
Line Voltage
Displays the voltage coming through the line attached to the MicroMMAC-T.
Battery Output
Displays the amount of battery output voltage.
Battery Capacity
Displays the percentage of remaining battery capacity (100% indicates a fully
charged battery).
Test Results
Displays the result of the last self-test performed by the UPS. The possible test
results are:
Unit OK
Unit Failed
Bad Battery
No recent test
Unit in test...
Please standby
2-26
Model 370
Model 400
Model 600
Model 900
Model 1250
Model 2000
Setting the UPS
ID, below, for instructions for setting
The UPS unit is in working order.
The UPS unit has failed the self-test. Check the
unit for damage or consult your UPS User's
Manual.
The UPS unit battery is bad.
No UPS self-test has been performed in the last
five minutes.
The UPS is currently in test mode.
Managing the Hub
