Adding New Modules

Adding new modules to an existing 5-slot carrier is very similar to installing the
control unit.
Use these instructions if you are adding modules to an existing 5-slot
carrier. If you are upgrading from a stand-alone PARTNER ACS
processor module to a 2-slot carrier, see
Processor Module and a 2-Slot Carrier" on page 14
CAUTION:
Before starting, verify that you have batteries installed in the processor
module by viewing the display of the telephone at extension 10.
Follow these steps to add a module to an existing 5-slot carrier:
Move the On/Off switch to the "Off" position ("O").
1
Remove the power cord from the wall outlet.
2
Perform the following steps to remove the cover:
3
Loosen the thumb screw at the bottom of the carrier cover.
a
Rotate the carrier cover to disengage the tabs at the top of the modules
b
from the openings on the top of the carrier cover.
Before installing a module, remove the clear, plastic protector from the
4
connector area on the rear of the module by grasping the tabs on the ends
of the protector and lifting.
6 Maintaining Your System
"Wall-Mounting a Stand-Alone
for instructions.
Adding New Modules 75
