Follow these steps to wall-mount the module(s):
Using the enclosed template, mark the screw locations on the wall.
1
Hold the processor module against the wall with the line and extension
2
jacks facing left. Leave at least 1 foot (0.3 meter) clearance at the top, front,
and right side, and at least 2 feet (0.6 meter) at the bottom and left side.
Insert a #8 sheet metal screw into the screw hole at the top of the processor
3
module.
If you are installing a second module, go to Step 5. If you are not installing a
4
second module (stand-alone configuration):
Insert another #8 sheet metal screw into the screw hole at the bottom of
a
the module.
Tighten the screws until the mounting tracks are snug against the wall.
b
There must be a 3/8 inch (1 cm) gap between the wall and the rest of the
module. Do not overtighten the screws or the module will warp and fail to
operate.
Go to the next procedure,
c
Remove the clear plastic protectors from the connectors on the right side of
5
the wall-mounted PARTNER ACS processor module and the module to be
added by grasping the tabs on the ends of the protector and lifting.
Slide the second module onto the PARTNER ACS processor module,
6
making sure the mounting tracks interlock.
Attach the 2-slot carrier to the top right side of the two modules, properly
7
engaging the connectors on the modules to the carrier.
Fasten the carrier to the modules by using the two #4 screws included with
8
the carrier.
Insert the 3-1/2 inch #8 screw into the bottom of the modules. Tighten it until
9
the mounting tracks of the PARTNER ACS processor module are flush
against the wall. Do not overtighten or the module will warp. Then go to the
next procedure,
"Labeling Jacks," on page
"Labeling Jacks," on page
2 Installing Your System
18.
