IP Interface Configuration
To display the following form, go to the IP Interfaces Configuration form. Select an IP Interface number, or open
the IP Interfaces folder and click Add IP Interface.
The switch can be configured with up to 256 IP interfaces. Each IP interface represents the switch on an IP subnet
on your network. The Interface option is disabled by default.
The following table describes the IP Interface Configuration controls:
Table 129
IP Interface Configuration controls
Control
IP Interface Identifier (1-256)
IP Address
Enabled?
Subnet Mask
VLAN Membership ID (1-4095)
Description
Selects an IP interface to configure.
Configures the IP address of the switch interface using dotted decimal notation.
Enables or disables this IP interface.
Configures the IP subnet address mask for the interface using dotted decimal
notation.
Configures the VLAN number for this interface. Each interface can belong to one
VLAN, although any VLAN can have multiple IP interfaces in it.
Configuring the switch 160
