RMON Alarm Configuration Table
To display the following form, select RMON > Alarm (click the underlined text, not the folder).
The following table describes the Alarm Groups Configuration controls:
Table 124
RMON Alarm Configuration controls
Control
Search Range
Search Options
Description
To search for a RMON Alarm, enter a range of numbers in the From and To fields.
To focus the search for a RMON Alarm, enter optional search parameters:
MIB OID
Interval
Rising Limit
Falling Limit
Rising Event Index
Falling Event Index
Alarm Type
Sample Type
Fields that have a value of "any" are ignored during the search.
Choose a search operation:
or: Search for Alarms specified in the search range that meet any of the criteria entered.
and: Search for Alarms specified in the search range that meet all of the criteria entered.
Click Search to display RMON Alarms that fit the range and meet the criteria entered.
Configuring the switch 155
