LACP Port Configuration
To display the following form, go to the Switch LACP Configuration form. Select a port number.
The following table describes the LACP Port Configuration controls:
Table 120
LACP Port Configuration controls
Control
Port Admin Key
Port Priority
Port LACP Mode
Uplink Fast General Configuration
To display the following form, select Layer 2 > UpLink Fast.
Description
Set the admin key for this port. Only ports with the same admin key and oper key
(operational state generated internally) can form a LACP trunk group.
Sets the priority value for the selected port. Lower numbers provide higher priority.
Default is 128.
Set the LACP mode for this port, as follows:
off: Turn LACP off for this port. You can use this port to manually configure a
static trunk. The default value is off.
active: Turn LACP on and set this port to active. Active ports initiate LACPDUs.
passive: Turn LACP on and set this port to passive. Passive ports do not
initiate LACPDUs, but respond to LACPDUs from active ports.
Configuring the switch 152
