VRRP Interfaces Configuration
NOTE:
This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > Virtual Router Redundancy Protocol > VRRP Interfaces (click the
underline text, not the folder).
The following table describes VRRP Interfaces Configuration controls:
Table 161
VRRP Interfaces Configuration controls
Control
Search Operation
Description
To focus the search for an virtual router, enter search parameters:
IP Interfaces
IP Address and subnet mask
VLAN ID
Fields that have a value of "any" are ignored during the search.
Choose a search operation:
or: Search for VRRP interfaces specified in the Search range that meet any of the criteria
entered.
and: Search for VRRP interfaces specified in the Search range that meet all of the criteria
entered.
Click Search to display VRRP interfaces that fit the range and meet the criteria entered.
Configuring the switch 193
