IP Static Route Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, go to the IP Static Routes Configuration form. Select a static route ID number, or
open the Network Routes folder and click Add Network Route.
The following table describes the IP Static Route Configuration controls:
Table 131 IP Static Route Configuration controls
Control
Route Table Index (1-128)
Destination IP
Mask
Gateway
Interface Number (1-256)

Static ARP Configuration

To display the following form, select Layer 3 > ARP (click the underlined text, not the folder).
This form summarizes the current static ARP entries. Select a static ARP ID number to display the IP Static ARP
Configuration form.
Description
Sets the numeric identifier for this index.
Enter the destination IP address for this route.
Enter the subnet mask for this route.
Enter the IP address of the gateway associated with this route.
Assigns an interface number to this route.
Configuring the switch 162
