Forwarding Database Information

To display the following form, select Layer 2 > FDB.
The forwarding database (FDB) contains information that maps the media access control (MAC) address of each
known device to the switch port where the device address was learned. The FDB also shows which other ports
have seen frames destined for a particular MAC address.
NOTE: The master forwarding database supports up to 8K MAC address entries on the MP per switch.
The following table describes the Forwarding Database Information controls:
Table 13 Forwarding Database Information controls
Control
Show Entries of a Specific Source Port
Show Entries of a Specific State
Show Entries of a Specific VLAN
Show Entry of a Specific MAC address
Clear Dynamic MACs
Entry #
MAC Address
VLAN
Source Port
Trunk
State
Learned Port
Permanent
Description
Displays FDB entries for the selected port(s).
Displays FDB entries by state.
Displays FDB entries for the selected VLAN.
Displays a single FDB entry by IP address.
Enter the MAC address using the format, xx:xx:xx:xx:xx:xx.
For example, 08:00:20:12:34:56
Removes learned FDB entries.
Displays the numeric identifier of the FDB entry.
Displays the MAC address of the FDB entry.
Displays the VLAN number of the FDB entry.
Displays the source port of the FDB entry.
Displays the trunk number of the FDB entry, if applicable.
Displays the port state of the FDB entry.
Displays the port number of the port that received the FDB entry.
Displays whether the FDB entry is a static, permanent entry.
